Vent A Hood® Premier Magic Lung® 30" Stainless Steel Wall Mounted Range Hood


Model #:

CWEH9-230SS

Model #: CWEH9-230SS
588704
Vent-A-Hood
$4,915.00

At a Glance

Product Dimensions 9"h x 30"w x 21"d

Thick rectangle styling. Click on the models for a list of our base model numbers for standard sizes; simply select the model you need, and then specify the finish (painted or stainless steel). Not available in real brass, real copper, or hammered copper. Recommended mounting height 27" above the cooking surface. Shown with matching wall mount duct covers (sold separately), available in standard sizes for 7', 8', and 9' ceiling heights or in custom sizes. All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.Read More

$4,915.00

What We Offer

Protect Your Purchase
None Selected
Services
None Selected
Clinton Quantity Available 0

Get to know this product.

Product Overview

Product Overview

Thick rectangle styling. Click on the models for a list of our base model numbers for standard sizes; simply select the model you need, and then specify the finish (painted or stainless steel). Not available in real brass, real copper, or hammered copper. Recommended mounting height 27" above the cooking surface. Shown with matching wall mount duct covers (sold separately), available in standard sizes for 7', 8', and 9' ceiling heights or in custom sizes. All Vent-A-Hood products are suitable for use in damp locations (outdoor applications such as a covered patio) when installed in a GFCI protected branch circuit.

Sones : 6.5

CFM: 600

Number of Lights : 2

Useful Documents
Specifications

General Specs

Width (in.)30
Height (in.)9
Duct Size (in.)8
Depth (in.)21
CollectionPremier Magic Lung®
ColorStainless Steel
Appliance Fit Width (cm.)76
Color Finish NameStainless Steel
Range Hood TypeWall Mounted
ENERGY STAR CertifiedNo
Appliance Fit Width (in.)30
Maximum CFM600
Bulb TypeLED
Sones Rating6.5
Height Above Cooktop27
Width (cm)76.2
Height (cm.)22.86
Depth (cm.)53.34
Height Above Cooktop Centimeter68.58
Voltage115
Noise Level (Sones)Standard - (High)
Ventilation TypeDucted

More Information

RPM1550
CFM SP@0.0"600
Equiv. CFM$900
CFM SP@0.1"531
CFM SP@0.2"480
CFM SP@0.3"430
